ES20
With innovative technologies derived directly from JBL Professional equipment, the JBL ES Series delivers powerful, accurate audio performance and brings the legendary JBL sound from concert stages, recording studios and cinemas to living rooms, dens,
bedrooms and patios. And with two finishes to choose from – black and cherry – they’re designed to look good anywhere, with a style that equals their substance.
General Specifications
Type
Bookshelf Finish Black
Series ES
Features
-
Audio Specifications:
Power Handling (Recommended) 60W
Nominal Impedance 8 Ohms
Maximum Recommended Amplifier Power 125W
Frequency Response (-3dB) 60Hz – 40kHz
Crossover Frequencies 3300Hz – 24dB/octave 12000Hz – 18dB/octave
Power Handling (Peak) 240W
Sensitivity (2.83V@1m) 86dB Specifications
-
Speaker Specifications:
Ultra High Frequency Transducer 3/4" (19mm) Polyester-film ring-radiator, shielded; EOS waveguide
High-Frequncy Transducer 3/4" (19mm) Titanium- laminate dome, shielded; EOS waveguide
Low-Frequency Transducer 5" (130mm) PolyPlas,™ shieldedDimensions:
Width (in) 6-7/8
Weight (lb) 10.3
Width (mm) 174
Height (in) 12-1/2
Weight (kg) 4.6
Height (mm) 318
Depth (in) 8
Depth (mm) 203
